Freestanding Wind Turbine Tower – 6 to 18 m in height, including structural analysis and foundation plan
The freestanding wind turbine tower is the ideal solution for all Deichturbinen
and small-scale wind power systems. It comes with a structural analysis,
It is supplied with foundation drawings and force application points, and—
—is ideally suited for the North Sea and Baltic Sea regions thanks to its surface protection designed to withstand marine air.
All masts are compatible with horizontal (H Series) and
vertical turbines (V Series) and are available in heights of
Available in lengths from 6 m to 18 m. Custom lengths are available at any time.
Advantages of the freestanding wind turbine tower
- Structural Analysis & Foundation Plan Included
- Surface protection suitable for coastal environments (North Sea & Baltic Sea)
- Compatible with all Deichturbinen (H & V series)
- Freestanding – no guy wires required
- Rugged, industrial-grade quality for 5–100 kW turbines
- Custom heights available upon request
What’s Included
- Wind turbine tower at the selected height
- Recording system for Deichturbinen
- Drawing of the tower showing force application points
- Foundation drawing with reinforcement
- Structural Analysis for the Tower and Foundation
Available Heights & Recommended Turbines
| Height | Compatible turbines |
|---|---|
| 6 m | H600, V600, H1000 Mini, H1000, H2000, V1000, V2000, V2500, V3000, V5000 |
| 9 m | H600, V600, H1000 Mini, H1000, H2000, H3000, V1000, V2000, V2500, V3000, V5000, H5000 |
| 12 m | H1000 Mini, H1000, H2000, V600, H3000, V1000, V2000, V2500, V3000, V5000, H5000 |
| 18 m | Available upon request for 10–100 kW turbines |
Technical data
| Characteristic | |
|---|---|
| Altitudes | 6–18 m |
| Installation | Freestanding, without guy wires |
| Surface Protection | Hot-dip galvanized + painted |
| Compatibility | H & V Series Deichturbinen |
| Structural Analysis | Includes tower and foundation |
| Foundation | Reinforcement plan included / Rebar cage optional |
| Weight | Depends on length and power |
Note on Approval
A permit may be required for towers taller than 10 m. See Wind Turbine and PV Legal
The structural analysis provided is intended for submission to the structural engineer.
Custom-Made Items
Would you like to build the mast yourself?
We will be happy to provide you with the dimensions of the connecting flange after you purchase a turbine.
Custom-Made Products
Do you need a special mast?
Please provide us with the necessary dimensions, and we will adapt the mast to our turbines.
.
